Dimensions Guide

There are various types of motorcycles, the specifications depending on the target audience. The following are models from well known manufacturers.

Motorcycle Dimensions: 2010 Ducati 1198R Corse SE Special Edition

The Ducati 1198R has a wheelbase measuring 1430mm (56.3in). The rake is 24.5 degrees. The front wheel travel is 120mm (4.7in). The front wheel is 7-spoke (forged light alloy). The front tire is 120/70 ZR17. The rear wheel travel is 127mm (5in) and the rear tire is 190/55 ZR17.

The front brakes are semi-floating discs measuring 2 x 330mm. The rear brake is 245mm. The fuel capacity is 18l – 4.75 gallon (US). The dry weight is 168 kg (370.3 lb). The seat height is 820mm (32.2in). There are lights for turn signals, high-beam, oil pressure and neutral.

Motorcycle Dimensions: 2010 Honda CBR1000RR ABS

The Honda CBR1000RR has a curb weight of 439 lbs. The fuel capacity is 4.7 gallons and has a 1.06-gallon reserve. The trail is 96.2mm (3.8 inches). The rake is 23.3 degrees and the wheelbase is 55.4 inches. The front and rear tires are 120/70ZR-17 radial and 190/50ZR-17 radial, respectively.

The front brakes are 320mm discs (dual radial mounted 4-piston calipers). The rear is a 220mm disc. The engine type is liquid-cooled inline four-cylinder (999cc). The compression ratio is 12.3:1. The bore and stroke specifications: 76mm x 55.1mm. The transmission is close-ratio 6-speed.

Motorcycle Dimensions: 2010 Kawasaki Versys

The bike is 83.7 in long, 33.1 in wide and 51.8 in high. The displacement is 649cc and the bore and stroke is 83.0 x 60.0mm. The compression ratio is 10.6:1. The transmission is 6-speed. The rake is 25 degrees and the trail is 4.3 inches.

The wheelbase is 55.7 in. The engine is 4-stroke, 4-valve per cylinder (liquid cooled). The fuel system is digital fuel injection with 38mm Keihin throttle bodies. The frame is high-tensile steel (semi-double cradle).

The front tire is 120/70×17 and the rear tire is 160/60×17. The seat height is 33.1 in and the curb weight is 454.1 lbs. The fuel capacity is 5.0 gallons.

Motorcycle Dimensions: 2010 Yamaha V-Max VMX17

The length is 2,395mm (94.3") and the height is 1,190mm (46.9"). The wheelbase is 1,700 mm (66.9") and the width is 820mm (32.3"). The rake is 31 degrees and the trail is 148mm (5.8").

The ground clearance is 140mm (5.5") and the seat height is 775mm (30.5"). The fuel capacity is 15 liters. The net weight is 310 kg (683 lb). The color is a deep red. The front tire is 120/70R18 and the rear tire is 200/50R18.

The front brakes are 320mm discs (dual with ABS). The rear brakes are 298mm disc. The rear suspension is adjustable. The transmission is 5-speed. The fuel consumption is 11.4kpl / 32mpg. The maximum torque is 17 kg-m (123 ft-lb) at 6,500 rpm.

Keep in mind that motorcycle dimensions are subject to modifications. The manufacturers may at any time change them. As a buyer, it is always wise to check with the manufacturer or seller to get the exact specs.
