Harley Davidson Softail Sizes

Below are the specifications for some 2010 Softail models.Harley Davidson Softtail When assessing Harley Davidson Softail bikes, being aware of these facts and figures can be helpful.

Harley Davidson Softail Dimensions: Classic FLSTC

The Classic FLSTC is 94.50 in. (2400.30 mm) long, 55.20 in. (1402.08 mm) high and 37.60 in. (955.04 mm) wide. The seat height is 25.50 in. / 647.70 mm (Laden2); 27.10 in. / 688.34 mm (Unladen). The trail is 5.80 in. (147.32 mm) and the ground clearance is 5.10 in. (129.54 mm).

The rake (steering head) is set at 31 degrees. The fork angle is 31 degrees and the wheelbase is 64.50 in. (1638.30 mm). The tires are Dunlop Harley Davidson Series, blackwall bias (front: D402F MT90B16 72H; rear: D401 150/80B16 71H). The fuel capacity of the Classic FLSTC is 5 gal (18.93 L). The running order weight is 761.25 lbs. (345.30 kg).

Harley Davidson Softail Dimensions: Fat Boy FLSTF

The Fat Boy FLSTF is 94.30 in. (2395.22 mm) long, 39.20 in. (995.68 mm) wide and 44.50 in. (1130.30 mm) high. The seat height is 25.40 in. / 645.16 mm (Laden2); 27.50 in. / 698.50 mm (Unladen). The fork angle is 31 degrees and so is the rake.

The ground clearance is 5.10 in. (129.54 mm). The wheelbase is 64.50 in. (1638.30 mm) and the trail is 5.80 in. (147.32 mm). The tires are Dunlop Harley Davidson Series, radial blackwall (front: D408F 140/75R17 67V; rear: D407 200/55R17 78V). Its fuel capacity is 5 gal (18.93 L). The weight (running order) is 725.25 lbs. (328.97 kg).

Harley Davidson Softail Dimensions: Fat Boy Lo FLSTFB

The Fat Boy Lo FLSTFB is 94.30 in. (2395.22 mm) long, 39.20 in. (995.68 mm) wide and 44.30 in. (1125.22 mm) high. The seat height is 24.25 in. / 615.95 mm (Laden2); 26.35 in. / 669.29 mm (Unladen). The fork angle is at 31.6 degrees and the ground clearance measures 4.80 in. (121.92 mm).

The rake (steering head) is 31.6 degrees. The trail is 5.80 in. (147.32 mm) and the wheelbase is 64.50 in. (1638.30 mm). Its’ tires are Dunlop Harley Davidson Series, radial blackwall (front: D408F 140/75R17 67V; rear: D407 200/55R17 78V). The fuel capacity is 5 gal (18.93 L). The weight is 731.25 lbs. (331.70 kg).

Harley Davidson Softail Dimensions: Deluxe FLSTN

The Deluxe FLSTN is 94.70 in. (2405.38 mm) long, 38.60 in. (980.44 mm) wide and 44.30 in. (1125.22 mm) high. The seat height is 24.50 in. / 622.30 mm (Laden2); 25.90 in. / 657.86 mm (Unladen). The ground clearance is 4.80 in. (121.92 mm) and the rake (steering head) is 32.1 degrees.

The fork angle is 32 degrees. The trail is 5.80 in. (147.32 mm) and the wheelbase 64.50 in. (1638.30 mm). The tires are Dunlop Harley Davidson Series, wide whitewall (front: D402F MT90-16 72H; rear: D402 MU85B16 77H). The fuel capacity is 5 gal (18.93 L). The running weight order is 726.25 lbs. (329.43 kg).

The Harley Davidson Softail dimensions mentioned here is an overview. Always consult the seller for more specific information.
