Night Vision Goggles Sizes

Once confined to military use, night vision goggles are now available as toys, items or accessories for adventurers. The features vary per product, but you can use the following as a guide.

Dimensions of Night Vision Goggles: ATN Viper

The ATN Viper measures 5 x 2 x 1 inches and weighs 9 ounces. The power supply is 3-volt lithium battery and the diopter +/- 5. The field of view is 14 degrees and the focal range is a foot to infinity. The minimum light needed is 3×0.001 lux.

The recognition range is 100 meters and detection range is 150 meters. The resolution is 40 lp/mm and the lens system, 35mm, f/1.0. The intensifier tube is 1st-gen +1 high resolution. The Viper is waterproof and resistant to dust. It also has brightness control. The unit comes with a case.

Dimensions of Night Vision Goggles: Night Owl Tactical Series G1

The Night Owl Tactical Series G1 dimensions are 4.6 x 4.2 x 2.1 inches (W x H x D). It weighs 14 ounces. The magnification is 1x. The range of view is 455 feet and the max resolution is 35 lp/mm.

The spectral sensitivity is 400 to 900 nm and the aperture 1:1.4. The objective lens focal length is 26 mm while the close focusing distance is 9.5 inches. The field of view at 1,000 yards is 1,742 feet and the number of objective lens elements is four. The diopter adjustment is -4 to +4. The ocular lens is glass.

Dimensions of Night Vision Goggles: EyeClops Night Vision

The EyeClops Night Vision measures 12 x 4 x 11.5 inches and weighs 1 pound. It can see up 50 ft in pitch black. The design is similar to a handheld binocular. The device is operated by infrared technology. Aimed for kids, the device has dual-eye LCD display and the focus can be adjusted.

The eyepiece can be adjusted so kids will feel comfortable wearing it. There is also a neck strap so it does not fall off. The stealth mode removes the light from the goggles, making you hard to see in the dark. The long range mode lets you see objects from afar.

Dimensions of Night Vision Goggles: EyeClops Night Goggles

The EyeClops Night Goggles measures 7 x 10 x 12 inches and weighs 1.8 pounds. The device works using infrared technology and lets you see up to 50 ft away in the dark. It is ideal for kids playing in the backyard during nighttime.

The goggles require five AA batteries. After the batteries are in place, the goggles can be turned on. The rubber straps around the goggles let you make adjustments until it fits. The goggles possess a hinged eye piece that can be flipped up. There is also a button for switching between a black and white screen to a green one.

The features and dimensions of night vision goggles also depend on how they will be used. Those for kids have basic features, while the ones for outdoor use are more advanced.
