Dimensions Guide

Moped dimensions and specifications depend upon the model and the manufacturer. The following are some of the features of these motorcycles. This can serve as a point of comparison if you are buying one.

Suzuki TR 50 SD Specifications

The Suzuki TR 50 is 975 mm (38.4 inches) high, 1,645 mm (64.8 inches) long and 715 mm (28.1 inches) wide. The dry weight is 80.0 kg (176.4 pounds). The ground clearance is 120 mm (4.7 inches). The wheelbase measures 1,080 mm (42.5 inches). The displacement is 49.00 ccm (2.99 cubic inches).

A study of the moped dimensions will show it has a single cylinder, two-stroke engine. The power is 7.20 HP (5.3 kW) at 7000 RPM. The torque is 7.60 Nm (0.8 kgf-m or 5.6 ft.lbs) at 6500 RPM. The front tire size is 120/80-12 54J and the rear is 120/80-12 54J.

Suzuki QuadSport Z50 Specifications

The seat height is 535 mm (21.1 inches) and the length is 1,270 mm (50.0 inches) overall. The ground clearance is 120 mm (4.7 inches). The fuel capacity is 2.60 liters (0.69 gallons).

The displacement is 49.00 ccm (2.99 cubic inches). The moped dimensions show the bore x stroke is 36.0 x 48.6 mm (1.4 x 1.9 inches).

The engine is single cylinder, four-stroke. It has a lubrication splash system and automatic gearbox. The transmission type is chain. The specs for the front suspension are: oil damped, coil spring, swing axle, independent. The rear specs are: oil damped, coil spring, swingarm type.

The front tire is 16/7-AT10 and the rear tire is 16/10-AT9. The front and rear brakes are drum brakes (expanding brakes). It weighs 78.0 kg (172.0 pounds).

1976 Suzuki AP 50 Specifications

The 1976 Suzuki AP 50 has a dry weight of 74.0 kg (163.1 pounds). The fuel capacity is 6.05 liters (1.60 gallons). The displacement is 49.00 ccm (2.99 cubic inches). The engine is single cylinder, two-stroke. The power is 4.80 HP (3.5 kW).

The moped has a maximum speed of 88.5 km/h (55.0 mph). It has rotary valves for fuel control. The gearbox is 5-speed and has dry plate clutch. The fuel consumption is 4.70 liters/100 km (21.3 km/l or 50.05 mpg). There is a single type exhaust system.

The moped dimensions and specifications specified here do not necessarily apply to other Suzuki mopeds. It is also possible for the manufacturer to alter the dimensions of these motorcycles at any time.
